Low Noise Biological Safety Airtight Angle Rotor Low Speed Centrifuge
Bench-top low-speed centrifuge TD4: widely used in experiments with small sample volume, many steps, large centrifugal force, and low temperature requirements. Such as: biochemistry, genetic engineering, agriculture and forestry disciplines,
The separation of samples in laboratories of food hygiene, hospitals and other scientific research institutions.
| Host technical parameters |
| product name | TD4 |
| Maximum speed (r/min) | 4000 |
| Maximum centrifugal force (×g) | 2600 |
| Maximum capacity | 8×20 ml |
| Speed accuracy | ±50r/min (can be customized according to requirements, multiples of 10) |
Features of the TD4 desktop low-speed centrifuge:
1. Adopting the single-chip microcomputer of Infineon and Infineon's drive module, with the independent research and development of the control panel and the high-torque DC brushless motor, the operation is stable and low noise, providing a comfortable laboratory environment.
2. It has multiple early warning functions such as over-speed, over-temperature, imbalance, etc., and a special combination of shock-absorbing devices makes the motor run smoothly and safely and reliably, prevents the sample from resuspending, and achieves an excellent centrifugal effect.
3. 100V-230V wide voltage design to improve the voltage adaptability range of the centrifuge (optional).
4. TFT-LCD true color display, double operation modes of touch screen buttons and physical buttons, with dedicated keys for centrifugal force display, and display setting parameters and operating parameters at the same time. Parameters can be changed at any time during operation without stopping the machine. The operation interface is intuitive, Simple and easy to use; the operating menu can be provided in multiple languages (Chinese, English, Russian, Portuguese).
5. The bio-safety airtight angle rotor adopts a silicon rubber integral sealing ring (EU RoHS 2015/863), which can avoid aerosol spillage and fully guarantee the safety of the staff and the laboratory environment.
6. The rear austenitic 304 stainless steel centrifugal cavity is equipped with all-steel spray-plastic shell, one-piece stamped and formed steel front face and three-layer steel protective cover and other security devices, which are both sturdy and durable, and ensure the safety of staff and laboratories. .
7. The use of silent electromechanical integrated motor door lock is easy to use. Just gently close the door cover, and the door lock system will be triggered to lock the door cover safely.
8.10-speed acceleration and 10-speed deceleration rate control, 20 groups of user-defined programs can be stored, which is convenient for calling common programs, and starting up is the last used program.
9. With CFDA filing and CFDA production qualifications, it has passed ISO 9001 (2015) certification and ISO 13485 (2016) certification.
